Self Lubricating Bearing Pad Composite Hatch Cover Bearing Pads

Self Lubricating Bearing Pad Composite Hatch Cover Bearing Pads
Self Lubricating Bearing Pad Composite Hatch Cover Bearing Pads

Large Image :  Self Lubricating Bearing Pad Composite Hatch Cover Bearing Pads

Product Details:
Brand Name: PVB
Model Number: JDB-P 090

Self Lubricating Bearing Pad Composite Hatch Cover Bearing Pads

Description
Description: Composite Hatch Cover Bearing Pads Material: Synthetic Fiber+reinforced Epoxy Resin
Thickness: Based On Requirment Lubrication: Self-lubricated,maintentance-free
Advantages: Self Lubrication, Long Service Life,coast Saving Application: Marine Hatch Cover
High Light:

Self Lubricating Bearing Pad pvb

,

Self Lubricating Bearing Pad Composite

,

Composite Hatch Cover Bearing Pads





Self lubricating composite hatch cover bearing pads





JDB-P 90 self-lubricating composite bearing pad is made of synthetic fiber, reinforced epoxy resin and added with wear resistant material.This material is featured in its low coefficient of friction,high mechanical property,excellent demensional stability,good chemical and corrosive resistance,and electrical insulation properties.





Material Structure






Synthetic fiber+reinforced epoxy resin+Mixture





Advantages




  • low coefficient of friction

  • high mechanical property

  • excellent demensional stability

  • good chemical and corrosive resistance

  • electrical insulation properties.





Application


  • Bearings of ships
  • Support pad of hatch covers
  • Shipbuildings,marine components
  • Components for pumps
  • Components for hydroelectric power



Technical Data




Specification

Color

Density (g/m³ )

Compressive strength (MPa)

Coefficient of Friction(Dry)

Working temperature

Max.temp.

Min.temp.

PFC-90

Green or Gray

1.3-1.5

350

0.14

120

-40
